JMW Design Consultancy Limited
One Stop shop, Re-Design through to Production
We specialise in re-designing obsolete Printed
Circuit Assemblies
Are you unable to manufacture existing assemblies due to obsolete components?
Non competitive assembly, due to over designed electronics utilising costly and difficult to source / long lead time components?
What we can do
From your original design we will provide to you the completed updated assemblies using up-to-date or more widely used and standard components:-
We need the Schematics / PCB files (but not essential), Parts list and 2 reference Assemblies, and preferably a specification.
If a specification is not available then the original assembly will be used as a base line.
From this we will provide to you a unit cost and delivery schedule, prototype, then production samples / batches
If the design is not changed much (different package / different manufacturer) and the changes are analysed for product impact (rise / fall times / impedance similarity then EMC re-testing may not be necessary, but may be required.
Expertise
JMW Design Consultancy has been operating since 1993, We have electronic design expertise in the following fields:-
Commercial (Battle field Simulation, Laser Target, NMR Pulse Generator)
Industrial (Hand Held Computer, Paper Collation Machine, Safety Critical Shutdown Systems)
Automotive (Engine Management Controllers, Voice amplification, Gear box Interface)
Avionics, Commercial & Military (Break-by-wire interfaces, Power Generation Controller)
Technologies used
Power Electronics,
Passives from through hole to smd down to 0402
Semiconductors from TO92, SMD, QFP, BGA, flip chip, chip and wire
Ceramic to FR4 substrate
Location
JMW Design Consultancy is based in North Oxfordshire 4 Miles from the M40 in the United Kingdom
